| Quantity: | |
|---|---|
Drive type | 4X2 |
Engine | |
Model | 4JB1CN |
Description | In-line/4 cylinder/water cooled/turbo charged/inter cooled/direct injection/diesel engine |
Rated power of engine (kw/HP) | 72/98 |
Maximum torque (N.m@rpm) | 220@1700 |
Displacement (ml) | 2771 |
Emission level | Euro IV |
Gearbox | |
Description | Manual,5 forward gears,1 reverse gear |
Front / Rear axle | |
Front axle load (Kg) | 1900 |
Rear axle load(Kg) | 3350 |
Type of tire | 7.00-16 14PR |
Quantity of tires | 6+1 |
Quantity of leaf spring | 8/6+5 |
Brake system | Drum type,hydraulic pressure double loop braking |
Steering device | Left hand drive,power steering |
Fuel tank capacity(L) | 100 |
Weight parameter | |
Curb weight (Kg) | 2370 |
Load weight(Kg) | 2500 |
Performance parameter | |
Maximum speed (km/h) | 98 |
Maximum grade ability (%) | ≤25 |
Dimension parameters | |
Overall dimension (LxWxH)mm | 5850×1880×2240 |
Box dimension (mm) | 4100×1790×380 |
Wheelbase (mm) | 3360 |
Cabin | |
Description | Single row,two doors,standard configuration,radio,USB interface,air conditioner,safety belt |
